Top quality boards designed and built by Big Daddy Enterprises. We are striving to make the best boards on the market and currently focusing on many boards that are not being made. All Big Daddy Signature items are listed on this page, if you wish to shop by category, please click on one of the links to the left (work in progress).

A Big Daddy Signature item. This is a brand new tester on the market, my own original design. Comes with a 9V battery adapter, powered by a 9V battery (not included) or a 9V-12V wall power supply (also not included). This makes for easy testing of the original or rebuilt Gottlieb System 1 and System 80 power supply harness. Very easy to understand and helps weed out problem harnesses.

Features
Easy to use and understand.
Red LED power indicator, Green LEDs for test.
Fully tested before sold.
Quality name brand parts used.
Professionally assembled in USA for top quality.
2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your part causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This is an idea that is meant to save some of the working System 1 MPU boards with corroded edge connectors. If you have a lot of corrosion on the MPU, this won't help much, but if it's minimal, this is a better solution than sanding or soldering direct as you can still retain all the original connectors and remove the board for service if needed. One common sign is if the game comes up with all zeros. Wire not included, takes even the novice about an hour to solder. I used solid core wires and once all were installed, it was pretty stiff and stable. Advice: I used a screwdriver to hold down the wire until the solder hardened up.


2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This is a replacement power supply board for Gottlieb System 80 & 80A pinball machines. Replaces Gottlieb part number B-19694. This is a different design than other boards available, you remove the top mounting bracket and screw directly to the backbox, using the bottom bracket as a ground.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable 5 Volt with readout.
• LED power indicators.
• Heatsink on voltage regulator has a proper thermal pad insulator, other makers use nothing.
• Test point loop connector for ground, test pads for all voltages.
• Ground wire attached.
• Locking headers in case you decide to replace the housings with the kit offered below
• All through hole readily available parts used on main board.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Alien Star, Amazon Hunt, Black Hole, Caveman, Circus, Counterforce, Devil’s Dare, Eclipse, El Dorado, Force II, The Games, Going Nuts, Haunted House, Ice Fever, Jacks to Open, James Bond, Krull, Mars God of War

A Big Daddy Signature item. This is a replacement Bus Jump board for the EM version of Bally's Evel Knievel. Yes, a solid state board in an electromechanical game. It drives bulbs that illuminate the translucent graphics in the backbox of EK jumping over a bus, if yours is missing or not working you may not even have known it exists. Does NOT come with mounting brackets or hardware.

Features

• Simple wire installation.
• LED indicators for jump lights.
• Quality through hole and socketed parts used throughout.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Evel Knievel (EM)

A Big Daddy Signature item. This is a replacement 16 Diode board for Williams Slugfest.

Features

• Quick and simple installation.
• Quality parts used throughout.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Slugfest

A Big Daddy Signature item. This is a replacement and *FUSED* Magnet board for The Addams Family Pinball machine. Many a playfield burn could have been prevented if this board were installed or the playfield magnets fused. When the transistor fail, they usually lock on and turn on the magnet which after a brief period of time will burn the playfield.

Features

• Quick and simple installation.
• Quality parts used throughout.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


The Addams Family including Gold edition

A Big Daddy Signature item. These are in stock on eBay item due to ease of choosing color and size: eBay Link.

If you order here, please check with me for size and color before ordering.

A Big Daddy Signature item. This is a replacement Flipper power supply for Williams System 9-11 games. This power supply was also used in Williams FIREPOWER II, a System 7 game and Data East games Laser War & Secret Service. Please note: Supplied with 5A fuse, games with an * require a 4A fuse (not included)

Features

• Quick and simple installation.
• Quality parts used throughout.
• LED power indicator.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Comet, F14 Tomcat *, Fire! *, Firepower II, Grand Lizard, High Speed, Laser Cue, Laser War, Millionaire *, Pin-Bot, Road Kings *, Secret Service, Sorcerer, Space Shuttle, Star Light

A Big Daddy Signature item. This is a replacement for the original 4.7K SRC that is no longer available. Recommended to direct solder. This SRC is SRC1,2, 3, 4, 5, 7, 8 & 9 on Williams System 11 boards reference Williams 5060-10396-00


2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This is a replacement for the original 1K SRC that is no longer available. Recommended to direct solder. This SRC is SRC6 on Williams System 11 boards, reference Williams 5060-10324-00.


2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This is a small lamp board for Costal Amusements redemption game, confirmed used in Slam Dunk, please email me if you know of others.

Features

• Quick and simple installation.
• Quality parts used throughout.
• New twist in bulb holder.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Slam Dunk

A Big Daddy Signature item thanks to the LISY Project. New updated board with 5Volt Power LED and ground lug. Uses readily available IRL540s. LED indicators for active IRL540s. Thanks to the LISY Project for making the data available. Please note, original Gottlieb games use regular incandescent light bulbs, modern LEDs may flicker (aka ghosting) and you may have to buy non ghosting LEDs or use regular light bulbs for switched lamps.

Features

• Quick and simple installation.
• Quality parts used throughout.
• All through hole parts readily available.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Alien Star, Amazon Hunt, Amazon Hunt II, Amazon Hunt III, Arena, Bad Girls, Big House, Black Hole, BoneBusters Inc, Bounty Hunter, Caveman, Chicago Cubs Triple Play, Circus, Counterforce, Devil’s Dare, Diamond Lady, El Dorado, Excalibur, Force II, The Games, Genesis, Going Nuts, Gold Wings, Haunted House, Hollywood Heat, Hot Shots, Ice Fever, Jacks to Open, James Bond, Krull, Mars God of War, Monte Carlo, Panthera, Pink Panther, Punk, Q*bert’s Quest, Rack Em Up, Raven, Ready Aim Fire, Robo-War, Rock, Rock Encore, Rocky, Royal Flush Deluxe, Spiderman, Spirit, Spring Break, Star Race, Striker, Super Orbit, Tag Team, The Games, Timeline, Touchdown, TX Sector, Victory, Volcano

A Big Daddy Signature item. This is a replacement opto board that replaces A-19359 in Williams Road Show. This board has two optical switches that determine the position of the dozer blade in front of Ted's head on the playfield. The motor shaft on the assembly has a plastic disc with one blade which passes through the two optical switches, please make sure your disc isn't warped to prevent damage to the optos.

Features

• Quick and simple installation.
• Quality parts used throughout.
• All through hole parts readily available.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This is a replacement Sound/Speech power supply board for the boards listed below. Please note if you have the power supply in the cabinet and not the head (MGOW and Volcano), I am working on an adapter and this one will not work as is. Complete board is game tested in my personal Haunted House.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Ground screw for optional ground mod wire.
• All through hole parts readily available.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Black Hole, Caveman, Devil's Dare, Haunted House, Krull, Mars God of War, Punk, Q*Bert's Quest, Rocky, Spirit, Striker, Super Orbit, Volcano.

A Big Daddy Signature item. This is a replacement Sound/Speech power supply board updated for Royal Flush Deluxe only.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Ground screw for optional ground mod wire.
• All through hole parts readily available.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This is a budget version of the Flash Gordon XENON bulb strobe unit I sell below. It uses four 6.3V LEDs so you can customize brightness and colors. I am supplying (4) four SMD white LEDs that may vary from board to board, and no guarantee you will like my choice. PLEASE NOTE: An unknown number of later production games did not include a xenon strobe board or its small transformer found in the lower cabinet on the power supply plate. This board does not require that transformer, only the connector in the head. Please check your game before ordering.

A Big Daddy Signature item. This is a budget version of the Flash Gordon XENON bulb strobe unit I sell below. It uses four 6.3V LEDs so you can customize brightness and colors. I am supplying (4) four SMD red LEDs that may vary from board to board, and no guarantee you will like my choice. PLEASE NOTE: An unknown number of later production games did not include a xenon strobe board or its small transformer found in the lower cabinet on the power supply plate. This board does not require that transformer, only the connector in the head. Please check your game before ordering.

A Big Daddy Signature item thanks to the LISY Project. Brand new Big Daddy BD-GTLB-SYS1-Driver replacement Gottlieb System 1 Driver board. Updated board with 5V power LED and ground lug. All (8) socketed ULN2803s are individually tested, and complete board is game tested in my personal Sinbad. Uses readily available IRL540s. Thanks to the LISY.dev Project for making the data available. Please note: Original Gottlieb games use regular incandescent light bulbs, modern LEDs may flicker (aka ghosting) and you may have to buy non ghosting LEDs or use regular light bulbs for switched lamps.

Features

• Quick and simple installation.
• Quality parts used throughout.
• LED Power indicator.
• Ground screw for optional ground mod wire.
• All ULN2803s tested before installation.
• All through hole parts used on main board readily available.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Asteroid Annie, Buck Rogers, Charlie's Angels, Cleopatra, Close Encounters, Count Down, Dragon, Genie, Hulk, Joker Poker, Pinball Pool, Roller Disco, Sinbad, Solar Ride, Torch, Totem

A Big Daddy Signature item thanks to the LISY Project. This is a newly designed and manufactured direct plug in replacement display set for any 6 digit Bally or Stern game. Each board is game tested in one of my personal games. Displays are 1 piece and you do not use the existing mounting bracket, just the screws. Currently the comma is a period (".") due to cost limitations. Foam surrounds will be available when I find a source, currently not included. Working on more pictures. Picture shown is all colors that will be available.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable dimmer control.
• Dot (comma) disabled by jumper.
• Widened holes allow for left to right adjustment.
• Uses 5 Volts so no more high voltage issues to address.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.



Bally:, Freedom,Night Rider,Black Jack,Evel Knievel,Eight Ball,Power Play,Mata Hari,Strikes & Spares,Lost World,Six Million Dollar Man,Playboy,Voltan,Supersonic,Star Trek,Paragon,Harlem Globetrotters,Dolly parton,Nitro Groundshaker,Silverball Mania,Rolling Stones,Mystic,Hotdoggin,Viking,Frontier, Stern:, Ali, Cosmic Princess, Dracula, Galaxy, Hot Hand, Lazer Lord, Lectronamo, Magic, Memory Lane, Meteor, Nugent, Pinball, Stars, Stingray, Trident, Wild Fyre

A Big Daddy Signature item thanks to the LISY Project. This is a newly designed and manufactured direct plug in replacement display set for any 7 digit Bally or Stern game. Each board is game tested in one of my personal games. Displays are 1 piece and you do not use the existing mounting bracket, just the screws. Currently the comma is a period (".") due to cost limitations. Foam surrounds will be available when I find a source, currently not included. Working on more pictures. Picture shown is all colors that will be available.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable dimmer control.
• Dot (comma) disabled by jumper.
• Can be used in 6 digit games with alternate 7 digit ROM enabled by jumpers, no wiring or modifications needed.
• Widened holes allow for left to right adjustment.
• Uses 5 Volts so no more high voltage issues to address.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.



Bally:, Black Pyramid, BMX, Centaur, Centaur II, Cybernaut, Eight Ball Deluxe, Elektra, Fireball Classic, Fireball II, Flash Gordon, Frontier, Kings of Steel, Skateball, Speakeasy, Spectrum, Spy Hunter, X's & O's, Xenon, Stern:, Big Game, Catacomb, Cheetah, Dragonfist, Flight 2000, Freefall, Iron Maiden, Nine Ball, Quick Silver, Seawitch, Split Second, Star Gazer, Viper

A Big Daddy Signature item thanks to the LISY Project. This is a newly designed and manufactured direct plug in replacement display set for any 6 digit Bally or Stern game. Each board is game tested in one of my personal games. Displays are 1 piece and you do not use the existing mounting bracket, just the screws. Currently the comma is a period (".") due to cost limitations. Foam surrounds will be available when I find a source, currently not included. Working on more pictures. Picture shown is all colors that will be available.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable dimmer control.
• Dot (comma) disabled by jumper.
• Widened holes allow for left to right adjustment.
• Uses 5 Volts so no more high voltage issues to address.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.



Bally:, Freedom,Night Rider,Black Jack,Evel Knievel,Eight Ball,Power Play,Mata Hari,Strikes & Spares,Lost World,Six Million Dollar Man,Playboy,Voltan,Supersonic,Star Trek,Paragon,Harlem Globetrotters,Dolly parton,Nitro Groundshaker,Silverball Mania,Rolling Stones,Mystic,Hotdoggin,Viking,Frontier, Stern:, Ali, Cosmic Princess, Dracula, Galaxy, Hot Hand, Lazer Lord, Lectronamo, Magic, Memory Lane, Meteor, Nugent, Pinball, Stars, Stingray, Trident, Wild Fyre

A Big Daddy Signature item thanks to the LISY Project. This is a newly designed and manufactured direct plug in replacement display set for any 7 digit Bally or Stern game. Each board is game tested in one of my personal games. Displays are 1 piece and you do not use the existing mounting bracket, just the screws. Currently the comma is a period (".") due to cost limitations. Foam surrounds will be available when I find a source, currently not included. Working on more pictures. Picture shown is all colors that will be available.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable dimmer control.
• Dot (comma) disabled by jumper.
• Can be used in 6 digit games with alternate 7 digit ROM enabled by jumpers, no wiring or modifications needed.
• Widened holes allow for left to right adjustment.
• Uses 5 Volts so no more high voltage issues to address.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.



Bally:, Black Pyramid, BMX, Centaur, Centaur II, Cybernaut, Eight Ball Deluxe, Elektra, Fireball Classic, Fireball II, Flash Gordon, Frontier, Kings of Steel, Skateball, Speakeasy, Spectrum, Spy Hunter, X's & O's, Xenon, Stern:, Big Game, Catacomb, Cheetah, Dragonfist, Flight 2000, Freefall, Iron Maiden, Nine Ball, Quick Silver, Seawitch, Split Second, Star Gazer, Viper

A Big Daddy Signature item thanks to the LISY Project. This is a newly designed and manufactured direct plug in replacement display set for any 6 digit Bally or Stern game. Each board is game tested in one of my personal games. Displays are 1 piece and you do not use the existing mounting bracket, just the screws. Currently the comma is a period (".") due to cost limitations. Foam surrounds will be available when I find a source, currently not included. Working on more pictures. Picture shown is all colors that will be available.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable dimmer control.
• Dot (comma) disabled by jumper.
• Widened holes allow for left to right adjustment.
• Uses 5 Volts so no more high voltage issues to address.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.



Bally:, Freedom,Night Rider,Black Jack,Evel Knievel,Eight Ball,Power Play,Mata Hari,Strikes & Spares,Lost World,Six Million Dollar Man,Playboy,Voltan,Supersonic,Star Trek,Paragon,Harlem Globetrotters,Dolly parton,Nitro Groundshaker,Silverball Mania,Rolling Stones,Mystic,Hotdoggin,Viking,Frontier, Stern:, Ali, Cosmic Princess, Dracula, Galaxy, Hot Hand, Lazer Lord, Lectronamo, Magic, Memory Lane, Meteor, Nugent, Pinball, Stars, Stingray, Trident, Wild Fyre

A Big Daddy Signature item thanks to the LISY Project. This is a newly designed and manufactured direct plug in replacement display set for any 7 digit Bally or Stern game. Each board is game tested in one of my personal games. Displays are 1 piece and you do not use the existing mounting bracket, just the screws. Currently the comma is a period (".") due to cost limitations. Foam surrounds will be available when I find a source, currently not included. Working on more pictures. Picture shown is all colors that will be available.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable dimmer control.
• Dot (comma) disabled by jumper.
• Can be used in 6 digit games with alternate 7 digit ROM enabled by jumpers, no wiring or modifications needed.
• Widened holes allow for left to right adjustment.
• Uses 5 Volts so no more high voltage issues to address.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.



Bally:, Black Pyramid, BMX, Centaur, Centaur II, Cybernaut, Eight Ball Deluxe, Elektra, Fireball Classic, Fireball II, Flash Gordon, Frontier, Kings of Steel, Skateball, Speakeasy, Spectrum, Spy Hunter, X's & O's, Xenon, Stern:, Big Game, Catacomb, Cheetah, Dragonfist, Flight 2000, Freefall, Iron Maiden, Nine Ball, Quick Silver, Seawitch, Split Second, Star Gazer, Viper

A Big Daddy Signature item thanks to the LISY Project. This is a newly designed and manufactured direct plug in replacement display set for any 6 digit Bally or Stern game. Each board is game tested in one of my personal games. Displays are 1 piece and you do not use the existing mounting bracket, just the screws. Currently the comma is a period (".") due to cost limitations. Foam surrounds will be available when I find a source, currently not included. Working on more pictures. Picture shown is all colors that will be available.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable dimmer control.
• Dot (comma) disabled by jumper.
• Widened holes allow for left to right adjustment.
• Uses 5 Volts so no more high voltage issues to address.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.



Bally:, Freedom,Night Rider,Black Jack,Evel Knievel,Eight Ball,Power Play,Mata Hari,Strikes & Spares,Lost World,Six Million Dollar Man,Playboy,Voltan,Supersonic,Star Trek,Paragon,Harlem Globetrotters,Dolly parton,Nitro Groundshaker,Silverball Mania,Rolling Stones,Mystic,Hotdoggin,Viking,Frontier, Stern:, Ali, Cosmic Princess, Dracula, Galaxy, Hot Hand, Lazer Lord, Lectronamo, Magic, Memory Lane, Meteor, Nugent, Pinball, Stars, Stingray, Trident, Wild Fyre

A Big Daddy Signature item thanks to the LISY Project. This is a newly designed and manufactured direct plug in replacement display set for any 7 digit Bally or Stern game. Each board is game tested in one of my personal games. Displays are 1 piece and you do not use the existing mounting bracket, just the screws. Currently the comma is a period (".") due to cost limitations. Foam surrounds will be available when I find a source, currently not included. Working on more pictures. Picture shown is all colors that will be available.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable dimmer control.
• Dot (comma) disabled by jumper.
• Can be used in 6 digit games with alternate 7 digit ROM enabled by jumpers, no wiring or modifications needed.
• Widened holes allow for left to right adjustment.
• Uses 5 Volts so no more high voltage issues to address.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.



Bally:, Black Pyramid, BMX, Centaur, Centaur II, Cybernaut, Eight Ball Deluxe, Elektra, Fireball Classic, Fireball II, Flash Gordon, Frontier, Kings of Steel, Skateball, Speakeasy, Spectrum, Spy Hunter, X's & O's, Xenon, Stern:, Big Game, Catacomb, Cheetah, Dragonfist, Flight 2000, Freefall, Iron Maiden, Nine Ball, Quick Silver, Seawitch, Split Second, Star Gazer, Viper

A Big Daddy Signature item thanks to the LISY Project. This is a newly designed and manufactured direct plug in replacement display set for any 6 digit Bally or Stern game. Each board is game tested in one of my personal games. Displays are 1 piece and you do not use the existing mounting bracket, just the screws. Currently the comma is a period (".") due to cost limitations. Foam surrounds will be available when I find a source, currently not included. Working on more pictures. Picture shown is all colors that will be available.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable dimmer control.
• Dot (comma) disabled by jumper.
• Widened holes allow for left to right adjustment.
• Uses 5 Volts so no more high voltage issues to address.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.



Bally:, Freedom,Night Rider,Black Jack,Evel Knievel,Eight Ball,Power Play,Mata Hari,Strikes & Spares,Lost World,Six Million Dollar Man,Playboy,Voltan,Supersonic,Star Trek,Paragon,Harlem Globetrotters,Dolly parton,Nitro Groundshaker,Silverball Mania,Rolling Stones,Mystic,Hotdoggin,Viking,Frontier, Stern:, Ali, Cosmic Princess, Dracula, Galaxy, Hot Hand, Lazer Lord, Lectronamo, Magic, Memory Lane, Meteor, Nugent, Pinball, Stars, Stingray, Trident, Wild Fyre

A Big Daddy Signature item thanks to the LISY Project. This is a newly designed and manufactured direct plug in replacement display set for any 7 digit Bally or Stern game. Each board is game tested in one of my personal games. Displays are 1 piece and you do not use the existing mounting bracket, just the screws. Currently the comma is a period (".") due to cost limitations. Foam surrounds will be available when I find a source, currently not included. Working on more pictures. Picture shown is all colors that will be available.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable dimmer control.
• Dot (comma) disabled by jumper.
• Can be used in 6 digit games with alternate 7 digit ROM enabled by jumpers, no wiring or modifications needed.
• Widened holes allow for left to right adjustment.
• Uses 5 Volts so no more high voltage issues to address.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.



Bally:, Black Pyramid, BMX, Centaur, Centaur II, Cybernaut, Eight Ball Deluxe, Elektra, Fireball Classic, Fireball II, Flash Gordon, Frontier, Kings of Steel, Skateball, Speakeasy, Spectrum, Spy Hunter, X's & O's, Xenon, Stern:, Big Game, Catacomb, Cheetah, Dragonfist, Flight 2000, Freefall, Iron Maiden, Nine Ball, Quick Silver, Seawitch, Split Second, Star Gazer, Viper

A Big Daddy Signature item thanks to the LISY Project. This is a newly designed and manufactured direct plug in replacement display set for any 6 digit Bally or Stern game. Each board is game tested in one of my personal games. Displays are 1 piece and you do not use the existing mounting bracket, just the screws. Currently the comma is a period (".") due to cost limitations. Foam surrounds will be available when I find a source, currently not included. Working on more pictures. Picture shown is all colors that will be available.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable dimmer control.
• Dot (comma) disabled by jumper.
• Widened holes allow for left to right adjustment.
• Uses 5 Volts so no more high voltage issues to address.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.



Bally:, Freedom,Night Rider,Black Jack,Evel Knievel,Eight Ball,Power Play,Mata Hari,Strikes & Spares,Lost World,Six Million Dollar Man,Playboy,Voltan,Supersonic,Star Trek,Paragon,Harlem Globetrotters,Dolly parton,Nitro Groundshaker,Silverball Mania,Rolling Stones,Mystic,Hotdoggin,Viking,Frontier, Stern:, Ali, Cosmic Princess, Dracula, Galaxy, Hot Hand, Lazer Lord, Lectronamo, Magic, Memory Lane, Meteor, Nugent, Pinball, Stars, Stingray, Trident, Wild Fyre

A Big Daddy Signature item thanks to the LISY Project. This is a newly designed and manufactured direct plug in replacement display set for any 7 digit Bally or Stern game. Each board is game tested in one of my personal games. Displays are 1 piece and you do not use the existing mounting bracket, just the screws. Currently the comma is a period (".") due to cost limitations. Foam surrounds will be available when I find a source, currently not included. Working on more pictures. Picture shown is all colors that will be available.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable dimmer control.
• Dot (comma) disabled by jumper.
• Can be used in 6 digit games with alternate 7 digit ROM enabled by jumpers, no wiring or modifications needed.
• Widened holes allow for left to right adjustment.
• Uses 5 Volts so no more high voltage issues to address.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.



Bally:, Black Pyramid, BMX, Centaur, Centaur II, Cybernaut, Eight Ball Deluxe, Elektra, Fireball Classic, Fireball II, Flash Gordon, Frontier, Kings of Steel, Skateball, Speakeasy, Spectrum, Spy Hunter, X's & O's, Xenon, Stern:, Big Game, Catacomb, Cheetah, Dragonfist, Flight 2000, Freefall, Iron Maiden, Nine Ball, Quick Silver, Seawitch, Split Second, Star Gazer, Viper

A Big Daddy Signature item. You've asked for it time and time again. Finally: It's HERE! The random parts Big Daddy keychain. Strict Limit of 1 per order. You lost your keychain, OH NO! Order one here, problem solved! Warning: Due to rising bad parts prices, this product may be discontinued WITHOUT NOTICE!! When they're gone, THEY'RE GONE!

But really, 1 keychain per order please.... Features

• Quick and simple installation.
• Quality built and tested in the USA.
• Each is unique and cannot be duplicated!
• LIFETIME! Warranty against all manufacturing defects.

A Big Daddy Signature item. This is a newly designed and manufactured direct plug in replacement for the original hard to fix Gottlieb System 1 power supply board A2. Installation is simple, and comes with new mounting hardware to the OEM bracket (not included). Each board is game tested in my personal Sinbad.

Features

• Quick and simple installation.(Note)
• Quality parts used throughout.
• Adjustable 5 Volt with readout.
• Heatsink on voltage regulator has a proper thermal pad insulator, other makers use nothing.
• Test point loops connectors for grounds, test pads for all voltages.
• Ground solder point for optional ground mod wire.
• Locking headers in case you decide to replace the housings with the kit offered below
• All through hole readily available parts used on main board.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.

Note: OEM board will need to have 6 screws removed and the TO3 transistor either desoldered or broken off with pliers. New board requires no soldering. If this is daunting to you, order the board below with mounting bracket.


Asteroid Annie, Buck Rogers, Charlie's Angels, Cleopatra, Close Encounters, Count Down, Dragon, Genie, Hulk, Joker Poker, Pinball Pool, Roller Disco, Sinbad, Solar Ride, Torch, Totem

A Big Daddy Signature item. This is a newly designed and manufactured direct plug in replacement for the original hard to fix Gottlieb System 1 power supply board A2. Installation is simple, and comes preinstalled on an OEM bracket. $10 credit for returned OEM brackets. Each board is game tested in my personal Sinbad.

Features

• Quick and simple installation.
• Quality parts used throughout.
• Adjustable 5 Volt with readout.
• Heatsink on voltage regulator has a proper thermal pad insulator, other makers use nothing.
• Test point loops connectors for grounds, test pads for all voltages.
• Ground solder point for optional ground mod wire.
• Locking headers in case you decide to replace the housings with the kit offered below
• All through hole readily available parts used on main board.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Asteroid Annie, Buck Rogers, Charlie's Angels, Cleopatra, Close Encounters, Count Down, Dragon, Genie, Hulk, Joker Poker, Pinball Pool, Roller Disco, Sinbad, Solar Ride, Torch, Totem

A Big Daddy Signature item. This is a newly designed and manufactured direct plug in replacement for the original Bally/Williams Type 2 flipper board. Replaces the entire assembly part #A-17316.

Features

• Easy plug and play installation.
• Each is tested using a custom testing device.
• Quality parts used throughout.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Attack From Mars, Cactus Canyon, Champion Pub, Cirqus Voltaire, Congo, Corvette, Demolition Man, Dirty Harry, Flintstones, Indiana Jones, Indianapolis 500, Jackbot, Johnny Mnemonic, Judge Dredd, Junkyard, Medieval Madness, Monster Bash, NBA Fastbreak, No Fear, No Good Gofers, Popeye, Roadshow, Safe Cracker, Scared Stiff, Shadow, Star Trek The Next Generation, Tales of the Arabian Nights, Theatre of Magic, Who Dunnit, World Cup Soccer '94.

A Big Daddy Signature item. This is a fused replacement bridge board for the bridge rectifier located in the backbox of Williams pinball System 3 through System 11A machines, early Data East and early Sega games. Later games added the fuse, but if overfused, this bridge board can give you a 2nd layer of protection. Most games have two bridges, some games have three. These, now 30+ year old original bridge rectifiers, can fail, and there is no fuse between the transformer and bridge rectifier. If one does fail, it can ruin your wiring, transformer and even catch the game on fire. The Big Daddy BD-FUS-BR fused bridge board is easy to install, and comes with new spade lugs and a new screw as the bridge used is shorter than the original. All you have to do is remove your old bridge and replace it with this board. I recommend moving 1 wire over at a time to avoid mixing up wires (incorrect wire connections could damage the machine). An LED indicator shows DC voltage out of the bridge rectifier, and with this simple upgrade you are now protected!

Features

• Easy installation.
• LED indicates voltage at the bridge output.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Games list coming soon.

A Big Daddy Signature item. Brand new LED Display for Early System 80B Gottlieb/Premier pinball machines. Replaces System 80B display board MA644 or MA-644 (card edge).

Features

• Quick and simple Plug & Play installation.
• Bright Blue LEDs larger than originals.
• Dimmable via DIP switch.
• Red LED indicates proper board operation and power.
• Test Button lights all digits.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Used in the following Gottlieb/Premier System 80B Pinball Machines:, Arena, Bounty Hunter, Chicago Cubs Triple Play, Diamond Lady, Genesis, Gold Wings, Hollywood Heat, Monte Carlo, Raven, Robo-War, Rock, Rock Encore, Spring Break, Tag Team Pinball, TX Sector, Victory

A Big Daddy Signature item. 3D printed ion cannon for Data East Laser War. Make your game *POP* with a nice new and bright white ion cannon.

Features:
Comes with new decals already applied
Same thickness so lights shine through great (see video)
Corners and some detailed areas are more rounded than OEM
Finish is more satin like instead of shiny semi-gloss

A Big Daddy Signature item. This is a brand new flipper power supply board used ONLY on Addams Family and Addams Family Gold pinball machines This is a direct replacement and also contains the filter capacitor that was missing from the production versions of the game. For the fun of it, picture of the paper prototype.

Features

• Quick and simple installation.
• Quality built and tested in the USA.
• 2 Year Manufacturer’s Warranty against all manufacturing defects.

A Big Daddy Signature item. Power Supply/Voltage rectifier board used in early solid state Bally and Stern pinball machines, see game listing below. This board is designed as a replacement for the following: Bally AS-2518-18, Bally AS-2518-49, Stern TA-100. When designing this board we didn't just make a copy, we did our research and made improvements and fixed faults the OEM boards and other reproductions had. We looked at competitors and various OEM versions. I truly believe it is one of the best on the market. Professionally designed and assembled by a team having over 100 years of electronics experience!

Features

• This rectifier board uses top mounted bridge rectifiers with proper heat sinks, which is a design improvement over the original bottom mounted bridge rectifiers.
• Heat sink grease or compound is used, and not all makers take that step.
• All incoming wire “E” connection holes have traces on both top and bottom of board to ensure that the current can easily flow from the connection hole.
• The “E” connection numbers are silk screened on both the top and bottom of the board to facilitate wire installation.
• Redundant E9 and E10 connections are provided for the double wires used for games that had AS-2518-49 rectifier boards. All other E connections match those used on the AS-2518-18/TA-100 board, including redundant E7 and E8 connections.
• Six test points are provided at the top of the board (five for voltages and one for ground) so that even an amateur can easily measure board voltages.
• An LED indicator is provided next to each of the 5 voltage test points (TP1 through TP5). The LED is on when voltage is present.
• The printed circuit board is fabricated with thick 2 oz. copper and all traces meet or exceed the sizes recommended by IPC-2152 for current capacity.
• A ground plane is provided on both sides (top and bottom) of the board, and extra plated through hole connections have been added to ensure that the two planes are well connected.
• The negative output of each bridge rectifier is connected to the ground planes, which handles the high combined current from the bridge rectifiers.
• High current fuse clips are utilized for F1 and F5. The other fuses are well under 10 amps so normal fuse clips are used at those locations. Some other makers including OEM used underrated clips.
• The rectifier board mounting holes are identical to existing OEM boards.
• More wording under the fuses give information about their function and when fuses can be different.
• Quality name brand parts are used throughout. Fuses are quality Buss, Littelfuse or Bel fuses.
• Fuse spacing is correct compared to many reproductions that can leave as much as 1/2 of the fuse not contacting the clip causing heat issues, see 3rd picture.
• This rectifier board is built with readily available through-hole components to facilitate long term serviceability.
• All boards are tested with a custom made harness to ensure LEDs light. Randomly selected boards are fully installed with a transformer and offered for sale as a complete unit here or on eBay from time to time. One of the more common replacements was just "visually verified".

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.

Note that header J1 on this board has 9 pins (the 9th pin is only used for Bally AS-2518-49 replacement). If your game has a Bally AS-2518-18 board or a Stern TA-100 board, then your connector will only fit over 8 pins of J1 and the 9th pin will be unused. Connector kits are also available.

*** Safety Warning ***
The procedure involves cutting or desoldering wires from the old board and then soldering the wires onto the new board! You need to take extreme care to track which wire goes where. Big Daddy recommends installation be done by an experienced technician or seasoned hobbyist. Once installed and powered up, this rectifier board will have hazardous high voltages which include AC voltages (120V or 240V AC Line, 49V, and 173V) and DC voltages (230V and 43V). Extreme caution must be used by any person who is in the vicinity of this board. Remove power from the machine before doing any installation or removal work related to the board, including soldering/desoldering and connecting/disconnecting header connectors.
Game Listing, Bally:, Black Jack, Dolly Parton, Eight Ball, Evel Knievel, Frontier, Freedom, Future Spa, Harlem Globetrotters, Hotdoggin', Kiss, Lost, World, Mata Hari, Mystic, Night Rider, Nitro Ground Shaker, Paragon, Playboy, Power Play, Rolling Stones, Silverball Mania, Six Million Dollar Man, Skateball, Space Invaders (See Note 1 Below), Star Trek, Strikes and Spares, Supersonic, Viking, Voltan Escapes, , Game Listing, Stern, Ali, Big Game, Catacomb, Cheetah, Cosmic Princess, Cue (Rare, only six made), Dracula, Dragonfist, Flight 2000, Free Fall, Galaxy, Hot Hand, Iron Maiden, Lazer Lord (1 made), Lectronamo, Lightning, Magic, Memory Lane, Meteor, Nine Ball, Nugent, Orbitor 1, Pinball, Quicksilver, Seawitch, Split Second, Stargazer, Stars, Stingray, Trident, Viper, Wild Fyre

Here's a connector kit with everything you need to repair the connectors going to a Big Daddy BD-18/49/100, Bally AS-2518-18 or Stern TA-100 Power Supply. These Bally/Stern games are all over 30 years old, and the power supply and it's connectors are a sore spot for problems. If you bought one of my Power Supply rebuild kits, one of my new boards, or yours has been rebuilt, you probably need this. When the header pins burn, the pins in the housings and the plastic housings themselves get burned too. This kit contains the Trifurcon pins, which surrounds the pins on 3 sides, in two sizes for both wire sizes, (MUCH better than factory), new housings, and three key pins. Be aware of others selling with inferior parts!!

Here's a connector kit with everything you need to repair the connectors going to a Big Daddy BD-18/49/100 or Bally AS-2518-49 Power Supply. These Bally/Stern games are all over 30 years old, and the power supply and it's connectors are a sore spot for problems. If you bought one of my Power Supply rebuild kits, one of my new boards, or yours has been rebuilt, you probably need this. When the header pins burn, the pins in the housings and the plastic housings themselves get burned too. This kit contains the Trifurcon pins, which surrounds the pins on 3 sides, in two sizes for both wire sizes, (MUCH better than factory), new housings, and three key pins. Be aware of others selling with inferior parts!!

A Big Daddy Signature item. Power Supply/Voltage rectifier board used in early solid state Bally and Stern pinball machines, see game listing below. This board is designed as a replacement for the Bally AS-2518-54, AS-2518-132, and Midway's version A084-91616-A000 found in the lower cabinet of later classic Bally games. When designing this board we didn't just make a copy, we did our research and made improvements and fixed faults the OEM boards and other reproductions had. We looked at competitors and various OEM versions. I truly believe it is one of the best on the market. Professionally designed and assembled by a team having over 100 years of electronics experience!

Features

• Board is designed to replace the different -54 varieties: Assembly version 2948 413 had one 20Amp fuse at F5 for both the cabinet/playfield GI and the backbox GI, Assembly version 2948 544 had two 15Amp fuses splitting the GI.
• Board also replaces the -132 version found in Granny and the Gators and Baby Pacman, having 6A diodes. Please note you will need to change fuse F3 from 4A to 6A (not included).
• This rectifier board uses top mounted bridge rectifiers with proper heat sinks, which is a design improvement over the original bottom mounted bridge rectifiers. Heat sink grease or compound is used, and not all makers take that step.
• Six test points are provided at the top of the board (five for voltages and one for ground) so that even an amateur can easily measure board voltages.
• An LED indicator is provided next to each of the 5 voltage test points (TP1 through TP5). The LED is on when voltage is present.
• The printed circuit board is fabricated with thick 2 oz. copper and all traces meet or exceed the sizes recommended by IPC-2152 for current capacity.
• A ground plane is provided on both sides (top and bottom) of the board. The negative output of each bridge rectifier is connected to the ground planes, which handles the high combined current from the bridge rectifiers.
• High current fuse clips are utilized for F1, F5 and F6. The other fuses are well under 10 amps so normal fuse clips are used at those locations. Some other makers including OEM used underrated clips.
• The board mounting holes are identical to existing OEM boards.
• (7) brand new standoffs are installed. Not all mounting plates had all the holes drilled but it still keeps the board from flexing when connectors are plugged in. You will need to use your old screws, none are included.
• More wording under the fuses give information about their function and when fuses can be different. Please note F4 needs to be changed to a 7A fuse for 4 Flipper games (not included).
• Quality name brand parts are used throughout. Fuses are quality Buss, Littelfuse or Bel fuses.
• Fuse spacing is correct compared to many reproductions that can leave as much as 1/2 of the fuse end not contacting the clip causing heat issues, see picture.
• This power supply/rectifier board is built with readily available through-hole components to facilitate long term serviceability.
• All boards are tested installed in a game (Medusa). One of the more common replacements was just "visually verified".

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Baby Pacman, Black Pyramid, BMX, Centaur, Centaur II, Cybernaut, Eight Ball Deluxe, Eight Ball Deluxe Limited Edition, Elektra, Embryon, Fathom, Fireball II, Flash Gordon, Goldball, Granny and the Gators, Kings of Steel, Medusa, Mr. & Mrs. Pac-Man, Rapid Fire, Speakeasy, Spectrum, Spy Hunter, Vector, Xenon, X’s & O’s

A Big Daddy Signature item. Brand new combination power supply for Gottlieb/Premier System 80B & System 3 games. Replaces System 80B power supplies MA-645 and MA-831. Replaces System 3 power supply MA-1359. The System 80B is notorious for having a flaky potentiometer. It can cause resets when voltage drops, or cause board damage if it opens. Installation is simple, and comes with new mounting hardware

Features

• Quick and simple installation.
• Quality parts used throughout.
• 5 Volt (adjustable) readout.
• 5V and 12V output taps for adding custom mods.
• All through hole readily available parts used on main board.

2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.


Used in the following Gottlieb/Premier System 80B Pinball Machines: Amazon Hunt II, Amazon Hunt III, Arena, Bad Girls, Big House, Bone Busters Inc, Bounty Hunter, Chicago Cubs Triple Play, Diamond Lady, Excalibur, Genesis, Gold Wings, Hollywood Heat, Hot Shots, Monte Carlo, Night Moves, Raven, Robo-War, Rock & Rock Encore, Spring Break, Tag Team Pinball, TX-Sector, Victory,,Used in the following Gottlieb/Premier System 3 Pinball Machines: Barb Wire, Bell Ringer, Bullseye, Cactus Jack's, Car Hop, Caribbean Cruise, Class of 1812, Cue Ball Wizard, Deadly Weapon, Frank Thomas' Big Hurt, Freddy A Nightmare on Elm Street, Gladiators, Hoops, Lights...Camera...Action!, Mario Andretti, Nudge-It, Operation: Thunder, Rescue 911, Shaq Attaq, Silver Slugger, Stargate, Street Fighter II, Strikes 'N Spares, Super Mario Bros., Super Mario Bros. Mushroom World, Surf 'n Safari, Tee'd Off, Title Fight, Vegas, Waterworld, Wipe Out, World Challenge Soccer

A Big Daddy Signature item. This is a brand new replacement relay board used in only a few Bally & Williams System 11 games. It replaces part numbers A14423 or A-14423-1. Used for switching motors on and off. New & improved version over any on the market! You will need to use your original standoffs and screws. Connector kit available below.

Features
Plug & Play installation.
Genuine Molex headers with friction lock.
Stayed true to the look of the original design.
No need for zero ohm jumpers, and capacitors were never used.
Larger traces can handle 10%+ more current than the original board.
Bench tested (Power applied to operate relay).
Professionally assembled in USA for top quality.
2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This is a brand new replacement relay board used in many Bally & Williams System 11 games. It replaces part numbers C11998 or C-11998-1. Used for switching GI lamps on and off, motor control or solenoids, depending on the game. New & improved version over any on the market! You will need to use your original standoffs and screws. Connector kit available below.

Features
Plug & Play installation.
Genuine Molex headers with friction lock.
Stayed true to the look of the original design.
No need for zero ohm jumpers, and capacitors were never used.
Larger traces can handle 10%+ more current than the original board.
Game tested (Installed in Space Station).
Professionally assembled in USA for top quality.
2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This is a brand new connector kit for relays A144232, C11998 and C11092 used in many Bally & Williams System 11 games. Better crimp ends provided than factory. Can also be used on OEM boards

A Big Daddy Signature item. This is a brand new replacement keypad used in Bally 6803 games. Quality kept in mind, built using genuine Molex or Panduit headers, Omron switches, 3M rubber feet. Assembled in the USA by yours truly. Often missing or buttons don't work well.

Features
Game tested (Special Force).
Professionally assembled in USA for top quality.
2 Year Manufacturer’s Warranty against all manufacturing defects.

A Big Daddy Signature item. Brand new design, not a copy. Direct replacement for Bally AS-2518-66 and Midway A084-91618-A000 Solenoid expander boards. Please note games noted below require the jumper to be cut. Optional connector kit available below.

Features
Quality name brand parts used.
U14 Opto-isolator IC is socketed.
Brand new standoffs supplied (no screws).
Game tested in Medusa.
Locking headers since many games have them under the playfield.
Load resistor added so no light bulb needed.
Professionally assembled in USA for top quality.
2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This is a brand new ULN2803 IC tester. With all of the fakes and pulls being sold as new, and how some send ICs thrown in a bag, this is a needed item for those fixing WPC MPU and WPC driver boards and others. Location U20 on MPU boards, U19 on WPC 89 driver boards and U3 & U11 on WPC 95 driver boards. Quality kept in mind. Assembled in the USA by yours truly. Simple operation, 9V battery powered (comes with 9V connector, battery not included). Pressing S1 checks for any shorts, if an LED is lit, chip is bad. Pressing S2 at the same time turns on all transistors, if an LED is NOT lit, chip is bad. Picture shows 1 pin lifted demonstrating "bad" chip. Please note LED sizes and colors may vary. ICs shown not included. Last pic is an example of how chips are often sent these days.

Features
Simple operation
Small and portable
9V battery powered can be used on my other testers
Rubber feet on back for easy bench testing of many chips
Professionally assembled in USA for top quality.
2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your part causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This is a brand new 3081 IC tester. With all of the fakes and pulls being sold as new, and how some send ICs thrown in a bag, this is a needed item for those fixing many Bally & Stern solenoid driver boards and others. Quality kept in mind. Assembled in the USA by yours truly. Simple operation, 9V battery powered (comes with 9V connector, battery not included). Pressing S1 checks for any shorts, if an LED is lit, chip is bad. Pressing S2 at the same time turns on all transistors, if an LED is NOT lit, chip is bad. Picture shows 1 pin lifted demonstrating "bad" chip. Please note LED sizes and colors may vary. ICs shown not included.

Features
Simple operation
Small and portable
9V battery powered can be used on my other testers
Rubber feet on back for easy bench testing of many chips
Professionally assembled in USA for top quality.
2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your part causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This is a brand new replacement Sound Board, also called a Bells Module, for the early solid state Playmatic pinball machines.

Features
Individual pins to replicate the obsolete Playmatic 0.06 inch diameter pins on the board
Includes removable screw on terminals if your connectors are no good
ICs are all socketted
High Quality parts used throughout
Game tested
Professionally assembled in USA for top quality.
2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This is a brand new replacement Relay Board, also called a Relay Module, for the following Playmatic pinball machines: Space Gambler, Big Town, Chance, Last Lap, and Party. I added relays to all four positions, so this is a universal replacement that will take care of all applications (no matter how many relays Playmatic used). I actually used the same SPDT relay model in all four positions, but only the NO contact is used on the three right hand relays. From searching online, I never did find any application where the far right relay was used, but I included on the board just to be safe.

Features
Individual pins to replicate the obsolete Playmatic 0.06 inch diameter pins on the board
Includes removable screw on terminals if your connectors are no good
High Quality parts used throughout
Game tested
Professionally assembled in USA for top quality.
2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your game causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This is a brand new tester on the market, my own original design. Comes with a 9V battery adapter, powered by a 9V battery (not included) or a 9V-12V wall power supply (also not included). This makes for easy testing of the original or rebuilt Gottlieb System 1 MPU to Driver board harness. Very easy to understand and helps weed out problem harnesses. The push buttons are in order from 1-24 indicating those positions on A1-J5. The LEDs have a number next to it that indicate the position of the wire on A3-J1. In my example, I press button 8 and 9 and no LED, the LED is position 18 and 9. Both pins tone out with an ohmmeter at the back side of the wire, and the crimps look like they have good tension. But look at the third picture taken under close examination, corrosion. Replacement is needed, sanding is a poor solution! Harness shown for demonstration purposes only and not included.

Features
Easy to use and understand.
Red LED power indicator, Green LEDs for test.
Fully tested before sold.
Quality name brand parts used.
Professionally assembled in USA for top quality.
2 Year Manufacturer’s Warranty against all manufacturing defects. Understand that if your part causes a failure, this is not a warranty issue.

A Big Daddy Signature item. This replaces the obsolete LM379S (U23) Audio Amp IC used on Gottlieb System 80 pinball sound boards and some Gottlieb video game sound boards. This is board A6 in pinball machines, sometimes noted as MA-309, MA-215 or GV-10x and stamped B-20887-ver). This is the IC that has the large heat sink on it and often fails due to heat as the heat sink can fall off. Later versions used a MA-483 daughtercard and this has been untested as a replacement. This is an original design, not a copy.

A Big Daddy Signature item also on eBay item 284201511001. Flash Gordon Strobe Board assembly built with quality parts. You will need your original bracket and standoffs, or purchase below. Each unit is tested in an actual Flash Gordon pinball machine. For added safety, this board has redundant bleed resistors to discharge the high voltage capacitors. You should wait for one minute after removing power before handling the board in order to allow the capacitors to discharge. From the Internet: "Xenon flash lamps have a lifetime of hundreds of thousands of flashes Typically, the emission intensity is decreased by 50% after around 100,000 flashes" PLEASE NOTE: An unknown number of later production games did not include this board and requires a small transformer found in the lower cabinet on the power supply plate. Please check your game before ordering. If you have an original board, chances are you have the transformer but no guarantee someone didn't remove it.

A Big Daddy Signature item. Extra Big Daddy Flash Gordon Strobe Board built with quality parts. Requires careful soldering. This replacement is only for the Big Daddy Strobe Board Assembly, and does not fit the Bally factory strobe board! From the Internet: "Xenon flash lamps have a lifetime of hundreds of thousands of flashes Typically, the emission intensity is decreased by 50% after around 100,000 flashes".

A Big Daddy Signature item. Mounting bracket for Big Daddy Flash Gordon Strobe Board or Bally factory original.

A Big Daddy Signature item. (Still looking for the right parts, original length doesn't seem to be availabe). Mounting hardware for Big Daddy Flash Gordon Strobe Board or Bally factory original to the metal bracket.

A Big Daddy Signature item. This is a brand new replacement relay board used in many SEGA and Stern games. You will need to use your original standoffs and screws.

Please note Soldering is required!

The below boards and parts are in production and when available in quantity, will be for sale and announced on this site, Facebook and listed on eBay. If you would like to put on a waiting list, please email Todd at Big Daddy Enterprises

A Big Daddy Signature item. This is the description

A Big Daddy Signature item. This is the description

A Big Daddy Signature item. This is the description

A Big Daddy Signature item. This is the description

A Big Daddy Signature item. This is the description

A Big Daddy Signature item. This is the description
